Radio Configuration / Diagnostic Utility

User Manual
4 Radio Configuration / Diagnostic Utility
In This Chapter

Radio Status

Radio Network settings.......................................................................... 42

Security settings .................................................................................... 50

Radio access settings ........................................................................... 52

Apply Changes ...................................................................................... 56

Cancel Changes .................................................................................... 56

Factory Defaults .................................................................................... 56
The RadioLinx Industrial Hotspot radio has a built-in Radio Configuration /
Diagnostic Utility (radio web configuration form) that allows you to configure the
radio from any computer that can connect to the radio, through a wired Ethernet
connection, or through a Wireless connection.
You can use a web browser such as Microsoft Internet Explorer or Firefox on
your network-enabled desktop computer, laptop or Personal Data Assistant
(PDA) to monitor and change the settings within the RadioLinx Industrial Hotspot
radio.
To open the Radio Configuration / Diagnostic Utility
1 In the RadioLinx Industrial Hotspot Browser, select the radio to configure from
the list view or topography view, and then click the right mouse button to
open a shortcut menu.
2 On the shortcut menu, choose Connect. The Radio Configuration / Diagnostic
Utility will open in your web browser.
Or,
Double-click the selected radio to launch the Radio Configuration / Diagnostic
Utility.
ProSoft Technology, Inc.
May 25, 2010
.......................................................................................... 35
RadioLinx® Industrial 802.11abg Serial and Ethernet Client
RLXIB-IESC ♦ 802.11a, b, g
Page 31 of 98
