ETM Trace debugging connector (CN9)

Figure 13. ETM Trace debugging connector (CN9)

1. Top view

Table 29. ETM trace debugging connector (CN9)

Pin number (odd) Description
1 VDD power
3
5
7
9
11
13
15
17
19
Pin number (even)
2
GND 4
GND 6
KEY 8
GND 10
GND 12
GND 14
GND 16
GND 18
GND 20
DocID026738 Rev 1
Connectors
Description
TMS/PA13
TCK/PA14
TDO/PB3
TDI/PA15
RESET#
TraceCLK/PE2
TraceD0/PE3 or SWO/PB3
TraceD1/PE4 or nTRST/PB4
TraceD2/PE5
TraceD3/PE6
