ST-LINK/V2 USB type-B connector (CN5)
The USB connector, CN5, is used to connect the embedded ST-LINK/V2 to the PC for board
debugging.
Figure 11. USB type-B connector (CN5)
1. Front view
Table 25. USB type-B connector (CN5)
Pin number
1
2
3
4
5, 6
DocID026738 Rev 1
Connectors
Description
VBUS (power)
DM
DP
GND
Shield
31/61
