For the landing with Flaps DOWN enter the V
speed, 98 KIAS at the appropriate place on the TOLD.
(16) V Speed.
app
approach speed. It is V
instrument approach; V
approach; and, V plus 10 KIAS for a visual approach
ref
as determined by the PC.
For this example, the landing is planned with the
Flaps DOWN (100%) so the V
weather conditions are such that a normal instrument
approach back into the departure airport is planned in
the event of a takeoff emergency. Therefore, the V
will be V plus 20 KIAS.
ref
V is 98 KIAS + 20 KIAS = V
ref
Enter this speed in the appropriate block on the TOLD
card.
(17) Landing
measured from the landing touchdown, required to
land the aircraft and stop. Use Figure 7-30, Landing
Distance Without Propeller Reversing - Flaps 100%.
Do not use a headwind or headwind
component in calculating landing distance.
But, if a downwind landing is required,
then ensure the tailwind is factored.
Enter the chart
TEMPERATURE ~ ºC, +30 ºC.
intersecting the correct PRESSURE ALTITUDE ~
FEET line, 4000 feet. Trace horizontally to the right
until intersecting the
Maintain the same relative position between the
guidelines and trace down until intersecting the aircraft
weight line. From that point, trace horizontally to the
DISTANCE ~ FEET scale to determine the landing
distance.
For this example, the landing weight is 12,400
pounds. Assuming a takeoff emergency, the landing
weight may exceed the landing weight limit of 12,500
pounds.
The landing distance is 2,120 feet.
Enter that number, 2,120 feet, in the appropriate
block of the TOLD card. Remember, if the landing is
planned for touchdown to be at the 1000-foot markers,
then 3,120 feet will be required to accomplish this
landing with full flaps.
example of a completed TOLD Card front.
This is the intended final
plus 20 KIAS for a normal
ref
plus 10 KIAS for a stabilized
ref
is 98 KIAS.
ref
118 KIAS.
app
Distance. The distance,
NOTE
at the OUTSIDE
Trace up until
first REFERENCE
Refer to Figure 7-4 for an
ref
The
app
AIR
LINE.
Figure 7-4. TOLD Card (Example Completed)
g. Performance
Recommended Cruise Power, 1700 RPM charts
beginning at Figure 7-38 are normally used for cruise
performance planning.
Conversion, to determine the correct chart, relative to
ISA, for cruise performance planning.
example, the mission is planned to be flown at FL240.
(1) If a weather forecast provides the
forecast temperature at the cruise altitude, enter
Figure 7-11 at that temperature.
intersecting the planned PRESSURE ALTITUDE ~
FEET. At that point, determine the closest ISA +/-
guideline and use the corresponding chart for
planning.
If the forecast temperature for FL 240 is –10 ºC,
enter the chart at that temperature. Trace up until
TM 1-1510-218-10
Planning, Cruise.
Use Figure 7-11, ISA
For this
Trace up until
