TM 1-1510-218-10
been selected with the left outer knob, the page
number is selected by rotating the left inner knob.
The right side operates in a similar manner. The
navigation pages are available on both sides. The
remainder of the page types are different. Refer to
Table 3-2.
Only the right inner knob has both an in and an
out position. With the knob pushed in, it works exactly
as the left inner knob. In the out position, it performs a
waypoint scan function.
right inner knob is the in position.
(2) Waypoint Data Entry.
1. Press cursor to turn on the cursor
function.
PAGE IDENTIFIER
TRI
MOD
FPL
NAV
CAL
STA
SET
OTH
*Up to 10 with fuel management system and air data interfaces.
PAGE IDENTIFIER
CTR
REF
ACT
D/T
NAV
APT
VOR
NDB
INT
SUP
*Varies with the type of waypoints in the active flight plan.
3-10
The usual position for the
Table 3-1. Left Side Types
KNOB MARKING
TRIP
MODE
FPL
NAV
CALC
STAT
SETUP
OTHER
Table 3-2. Right Side Types
KNOB MARKING
CTR
REF
ACTV
D/T
NAV
APT
VOR
NDB
INT
SUPL
2. Rotate the outer knob to position the
cursor in the desired location.
location will vary. Waypoint identifiers
will be in different places on the page
depending on the type page selected.
3. Rotate the inner knob to select the
first character
identifier.
4. Move the outer knob one step
clockwise to move the cursor to the
second character position.
5. Rotate the inner knob to select the
second character.
6. Use the outer and inner knobs in this
manner until the complete waypoint
identifier is displayed.
PAGE NAME PAGE NUMBERS
Trip Planning
Mode
Flight Plan
Navigation
Calculator
Status
Setup
Other
PAGE NAME PAGE NUMBERS
Center WPT
Reference WPT
Active WPT
Distance/Time
Navigation
Airport WPT
VOR WPT
NDB WPT
Intersection WPT
Supplemental WPT
The
of the waypoint
0–6
1–2
0–25
1–5
1–7
1–5
0–9
1–4*
1–2
None
*
1–4
1–5
1–8
None
None
None
None
