(4) The class of the VOR. Refer to Table 3-
13 for VOR classifications.
Table 3-13. VOR Classification
DISPLAY
H
High altitude
L
Low altitude
T
Terminal
U
Undefined
(5) The VOR frequency.
(6) The published magnetic variation of the
VOR.
(7) The latitude and longitude of the VOR.
The nine VOR's nearest to the aircraft's present
position may be displayed.
displayed as part of the nearest VOR list, the latitude
and longitude are replaced with the bearing and
distance to the VOR.
NDB's which are combined with outer
markers (compass locators) are usually not
stored with NDB's.
always stored with intersections and are
found on the INT page by using the outer
compass locator name, not the NDB
identifier. There is also a nearest NDB list.
When an NDB page is displayed as one of
the
nearest
NDB's,
longitude are replaced with the bearing and
distance to the NDB.
v. NDB Page. Refer to Figure 3-26.
(1) The NDB Identifier. An arrow precedes
the identifier if it is the active waypoint.
(2) The name of the NDB.
(3) The NDB frequency.
(4) The latitude and longitude.
w. Intersection Page. The intersection pages
contain the named low altitude, high altitude,
approach, and SID/STAR intersections as well as
outer makers and outer compass locators. Refer to
Figure 3-27.
EXPLANATION
When a VOR page is
NOTE
However, they are
the
latitude
and
Figure 3-26. NDB Page
KENZY
REF:
RAD: 152.2
DIS:
N 39
W 94
Figure 3-27. Intersection Page
(1) The intersection, outer marker, or outer
compass locator name.
(2) The location of the intersection, outer
marker, or outer compass locator expressed in terms
of a radial and distance from a nearby VOR. The KLN
90B chooses the closest VOR. It takes a few seconds
for the VOR ident, radial, and distance to be calculated
and displayed.
(3) The
latitude
intersection, outer marker, or outer compass locator.
The identifier of another VOR may be entered in the
REF field, and the page will compute and display the
radial and distance from that VOR to the intersection.
This information is not stored with the INT page and is
lost when leaving the page.
1. Display the desired intersection page.
2. Press the right CRSR button to turn
on the cursor function.
TM 1-1510-218-10
MKC
o
3.7NM
o
13.25'
33.84'
o
INT
and
longitude
of
3-29
the
