- Page 1 Certified Flyers II BE76 Duchess Multi-Engine Study Guide 50 Airport Rd Suite 40 Morristown, NJ 07960 Tel: (973) 539-4080 Fax: (973) 539-1836 www.certifiedflyers.com March 2012...
-
Page 2: Table Of Contents
Aviation Regulations. Contents SECTION 1: MULTI-ENGINE AERODYNAMICS………………………………………….2 SECTION 2: AIRCRAFT SYSTEMS AND LIMITATIONS………………………………...7 SECTION 3: NORMAL FLIGHT PROCEDURES………………………………………….15 SECTION 4: EMERGENCY PROCEDURES……………………………………………….21 SECTION 5: MULTI-ENGINE IN-FLIGHT MANEUVERS………………………………25 APPENDIX 1: BE76 DUCHESS QUICK REFERENCE CHECKLIST…………………...29 APPENDIX 2: INSTRUMENT APPROACH BRIEFING “5 PHASES”…………………..31... - Page 3 On a conventional twin with propellers rotating clockwise, the critical engine is the left engine. On an aircraft such as the BE76 Duchess with counter-rotating propellers there is not a critical engine because the yawing and rolling caused from losing either engine is identical.
- Page 4 Certified Flyers II Duchess Multi-Engine Study Guide over the operating engines wing causing more lift on that wing, thus roll towards the inoperative engine. To counteract this roll and yaw, rudder pressure must be applied to the side of the operational engine to oppose these forces.
- Page 5 Certified Flyers II Duchess Multi-Engine Study Guide Single-engine absolute ceiling- the altitude where climb is no longer possible with one engine operating at full power and one engine’s propeller is feathered Vmc- MINIMUM CONTROL SPEED Rudder is applied to counteract yaw and roll from an inoperative engine in a multi-engine aircraft.
- Page 6 Certified Flyers II Duchess Multi-Engine Study Guide 2. Stall warning horn- a single engine stall may be just as dangerous as running out of rudder authority and could even result in a spin 3. Buffeting before the stall- same reason as the stall warning horn 4.
- Page 7 Certified Flyers II Duchess Multi-Engine Study Guide EFFECT ON PERFORMANCE Power Increase Up- more yaw Up- more power Temp Increase Down- less dense, less power, less yaw Down- less dense, less power Pressure Decrease Down- less dense, less power, less yaw Down- less dense, less power Density Altitude Down- less dense, less power, less yaw...
-
Page 8: Section 2: Aircraft Systems And Limitations
Certified Flyers II Duchess Multi-Engine Study Guide Section 2: Aircraft Systems and Limitations This study guide is only to supplement the aircraft POH, not to replace it. Refer to aircraft POH for official operating limitations and systems information. It is the pilot’s responsibility to be familiar with all information in the Pilots Operating Handbook. - Page 9 Certified Flyers II Duchess Multi-Engine Study Guide V-SPEEDS (KIAS) Rotation Speed Best Angle Climb Vxse Best Angle 1 Engine Best Rate Climb Vyse Best Rate 1 Engine Stall w/ Flaps Stall w/o Flaps Min Control 1 Engine Maneuvering (3000lb) Maneuvering (Max Gross) Max Structural Cruise Never Exceed Vsse...
- Page 10 Certified Flyers II Duchess Multi-Engine Study Guide LOAD FACTORS (3900 lbs) Positive maneuvering load factors: Flaps Up 3.8G Flaps Down (DN) 2.0G Negative Maneuvering load factor: Flaps Up ~1.52G KINDS OF OPERATION Minimum Flight Crew 1 Pilot 1. VFR day and night 2.
- Page 11 Fuel The BE76 Duchess uses aviation gasoline, grade 100 (green) or grade 100LL (blue). The fuel system is an “ON-CROSSFEED-OFF” arrangement and controlled by the fuel selectors located on the lower center floor panel.
- Page 12 Certified Flyers II Duchess Multi-Engine Study Guide A min of 9 gal of fuel must be present in each wing tank prior to flight. Total Capacity Total Usable FLIGHT CONTROLS The control surfaces are bearing supported and operated through the conventional cable assembly using push-rods and bell cranks.
- Page 13 (regardless of throttle position). ELECTRICAL SYSTEM Certified Flyers’ BE76 Duchess is equipped with a 12-volt, 35 ampere-hour lead-acid battery installed in a battery box in the aft fuselage compartment. Two 60 ampere, 14-volt, belt-driven alternators provide charging. The output of each alternator is controlled by a separate voltage regulator.
- Page 14 ENVIRONMENTAL The BE76 Duchess is equipped with a 45,000 btu Janitrol gas heater located on the right side in the nose compartment. This provides heated air for cabin warming and windshield defrosting.
- Page 15 Certified Flyers II Duchess Multi-Engine Study Guide The Duchess is equipped with two engine-driven, dry, pressure pumps interconnected to form a single system. If either pump fails, check valves will automatically close and the remaining pump will continue to operate all gyro instruments. A pressure gauge is located on the pilot’s subpanel and a no gyro annunciator light indicates loss of a pressure pump.
-
Page 16: Section 3: Normal Flight Procedures
Certified Flyers II Duchess Multi-Engine Study Guide Normal Flight Procedures Certified Flyers BE76 Duchess operating guidelines should be studied in addition to the aircraft POH, they are intended to be used in addition to the appropriate checklist. PASSENGER BRIEFING 1. Safety belt/harness usage 2. - Page 17 Certified Flyers II Duchess Multi-Engine Study Guide 5. Identify “Dead Foot, Dead Engine” 6. Verify by closing throttle 7. Feather Prop 8. Mixture to cutoff I will evaluate aircraft performance, execute an emergency, make appropriate radio calls, and land on any suitable runway. Departure Information ...
- Page 18 Certified Flyers II Duchess Multi-Engine Study Guide Recommended cruise power setting is 24” MP, 2300rpm. DESCENT Plan your descent well in advanced to avoid extended flights at power settings below 20” (plan 5 miles for every 1000’ to be lost for en route descent) ...
- Page 19 Certified Flyers II Duchess Multi-Engine Study Guide 1. Brief before landing and short-field landing checklist before entering the traffic pattern 2. Enter the pattern at or below 120 KIAS 3. Downwind abeam midfield extend gear and verify 3 green (no red), check visually 4.
- Page 20 Duchess Multi-Engine Study Guide INSTRUMENT APPROACHES The approach speed for the BE76 Duchess is 100 KAIS, this allows for better synchronization with other aircraft in the ATC system. Therefore, speed must be reduced between the DA/MDA before touchdown while “crossing the fence” whether flaps are used or not. Note, with a 100 KIAS approach speed, the BE76 fits into category B approach minimums (91-120 KIAS).
- Page 21 Certified Flyers II Duchess Multi-Engine Study Guide 13. Follow glideslope down to runway 14. Reduce power smoothly when landing is assured NON-PRECISION APPROACH 1. En-route: Approach should be fully briefed/ NAV aids set/checked/ Instruments checked 2. Slow to 120 KIAS (18” MP) within apx. 3 mins from initial approach fix/ or while given vectors to approach 3.
- Page 22 Certified Flyers II Duchess Multi-Engine Study Guide Before reaching FAF brief plan for circling approach: From MDA circle ____ (left/right) for RWY ____. Remain within 1.5 nm from RWY. If lose visual of RWY execute missed approach. (turn to parallel approach course and execute published missed) Continuing from Precision or Non-precision approach 1.
-
Page 23: Section 4: Emergency Procedures
Certified Flyers II Duchess Multi-Engine Study Guide Emergency Procedures These are emergency memory/review items only, they do not encompass all the emergency procedures listed in the POH. In any emergency or abnormal condition the POH should be consulted. MEMORIZE! IN-FLIGHT ENGINE FAILURE Airspeed Blue Line Mixtures... - Page 24 Certified Flyers II Duchess Multi-Engine Study Guide ENGINE TROUBLESHOOT “FIX” Trim As Req Fuel Selector Throttle Open 1/4" Fuel Pumps Primer Check Carb Heat Mixture Adjust Magnetos Check Fuel Quantity Check Fuel Pressure Check Oil Pres/Temp Check Cowl Flaps As Req ENGINE FAILURE SECURE “Feather”...
- Page 25 Certified Flyers II Duchess Multi-Engine Study Guide Fuel Selector Throttle 1/4" Aux Pump Magnetos Both Prop Move Forward Until engine windmills, then back to midrange, use starter momentarily if airspeed is below 100 KIAS. Mixture If engine fails to run, clear engine by allowing it to windmill with mixture in the FULL LEAN position.
- Page 26 Certified Flyers II Duchess Multi-Engine Study Guide Airspeed 85 KIAS Cabin Vents Closed Storm Window Open Upper Latch Open Latch Side Latch Open Latch EMERGENCY DESCENT Throttles Closed Props Full Forward Mixtures Rich Gear Down 140 KIAS Descend and Turn As Req ALTERNATOR LIGHT ILLUMINATES Ammeters...
- Page 27 Certified Flyers II Duchess Multi-Engine Study Guide Multi-Engine In-flight Maneuver Flow Checklists Through study and practice, flow checks should be performed from memory. Refer to PTS for completion standards for in-flight maneuvers. CLEARANCE TURNS FOR IN-FLIGHT MANEUVERS Scan area visually for traffic and begin set-up for in-flight maneuver. Maintain Altitude Perform 90 clearing turn to right or left Reduce power to 15"...
- Page 28 Certified Flyers II Duchess Multi-Engine Study Guide Trim Fuel Selectors Both On Cowl Flaps Both Open Crab Heat Both Off Throttles 15" MP Landing Gear Down Below 140 KIAS Aux Pumps Both On Mags/Masters Both/On Flaps Down in 10 Increments Mixture Both Full Rich Props...
- Page 29 Certified Flyers II Duchess Multi-Engine Study Guide For ATP, recover at first indication of impending stall (stall warning horn). For commercial, recover at first indication of aerodynamic buffeting. Breakers Visually Checked Trim Fuel Selector Both Open Cowl Flaps Both Open Carb Heat Both Off Throttles...
- Page 30 Certified Flyers II Duchess Multi-Engine Study Guide Not required for ATP. Breakers Visually Check Trim Fuel Selectors Cowl Flaps Left Closed/Right Open Carb Heat Left On, Right Off Throttles Both 15" MP Landing Gear Aux Pumps Mags/Masters Both/On Flaps Mixtures Both Rich Props Both High RPM Below 100 KIAS...
-
Page 31: Appendix 1: Be76 Duchess Quick Reference Checklist
Certified Flyers II Duchess Multi-Engine Study Guide Appendix 1: BE76 Duchess Quick Reference Checklists... - Page 32 Certified Flyers II Duchess Multi-Engine Study Guide...
-
Page 33: Appendix 2: Instrument Approach Briefing "5 Phases
Certified Flyers II Duchess Multi-Engine Study Guide Appendix 2: Instrument Approach Briefing “5 Phases” Transition Initial 6 T’s 6 T’s Course and Altitude Course and Altitude Straight In or Full Approach Slow to Approach Speed Weather Instruments Radios and Nav Everything Else -Review Approach -How low?
