Method Setting - GE ImageQuant LAS 4000 User Manual

5 Software reference guide
5.12 Option menu
5.12.2 Flat Frame Calibration
Flat Frame Calibration Pro
1 If FlatFrame Calibration Pro is selected in the Option menu, the window of the conditions preset
in the Method/Tray position window will be displayed.
2 Put the appropriate tray and calibration plate in the instrument.
3 Set the exposure time.
4 Enter a file name.
5 Click the Start button.

5.12.3 Method Setting

Method Setting is used to set the content displayed on the Method/Tray position screen.
•
To delete a method, select the method to be deleted and click Delete.
Note:
• To edit a method, select the method to be edited and click Edit.
Note:
• To add a method, click Add.
106
Only user-defined methods can be deleted.
Only user-defined methods can be edited.
ImageQuant LAS 4000 User Manual 28-9607-42 AB
