5 Software reference guide
5.6 Start
After exposure (type Increment, Repetition or
Program)
No. Description
1 The range can be changed by dragging the
mouse.
2 Gradation can be changed by dragging the
mouse.
3 The gradation conversion curve can be
changed (linear or sigmoidal).
4 The changed gradation is applied to all im-
ages.
5 Returns the gradation to the initial setting.

5.7 Sensitivity/Resolution

This function sets the sensitivity and resolution.
90
For magnified image view
2
1 3
For index image view
4
5
No. Description
6 Return to main screen.
7 Save image.
8 Print image or screen.
9 The selected image is marked by a yellow
frame. Click on an image to select it. Double-
click an image or click the Image tab to open
the magnified image view.
ImageQuant LAS 4000 User Manual 28-9607-42 AB
9
8
7
6
