2 The ImageQuant LAS 4000

2 The ImageQuant LAS 4000
This chapter describes the features and part names of the ImageQuant LAS 4000 hardware, and the
connectors that connect the various parts of the equipment.

2.1 The ImageQuant LAS 4000 exterior

Part
1
2
3
4
5
6
7
10
1
6
7
Name
Camera head
Indicator panel
Power LED
Busy LED
Error LED
Power switch
Intelligent dark box (IDX)
2
3
4
5
Description
CCD cooling and image data output
Status lights
Lights when the power is on
Lights when an exposure is in progress
Lights when an error is detected
I Power ON
O Power OFF
Dark box
ImageQuant LAS 4000 User Manual 28-9607-42 AB
