5 Software reference guide
5.8 Method/Tray position
Set the method and tray position
Method
The method (the combination of the optimum light source, filter, and iris) is registered for each detection
method. When a method is selected, the light source, filter, and iris are set automatically. The contents
of each setting are shown in the table below.
Note:
Method
Chemiluminescence
Fluorescence
92
The RGB module may be used instead of the separate red, green and blue Epi lights.
Option
SYBR Green
GFP
EtBr
Cy2
Cy3
Cy5
Dy781
DAPI
Light
None
Blue (460nm Epi)
Blue (460nm Epi)
UV (312nm Trans-illumi-
nation)
Blue (460nm Epi)
Green (520nm Epi)
Red (630nm Epi)
NIR (710nm Epi)
UV (365nm Epi)
ImageQuant LAS 4000 User Manual 28-9607-42 AB
Filter Iris
Through F0.85
Y515 Di F0.85
510DF10 F0.85
605DF40 F2.8
Y515 Di F0.85
575DF20 F0.85
R670 F0.85
IR785 F0.85
L41 F2.8
