Parts And Accessories - GE ImageQuant LAS 4000 User Manual

2 The ImageQuant LAS 4000
2.3 Connections
USB cable
Analysis PC
Note:

2.4 Parts and accessories

Epi tray
14
• Use the USB cable supplied with the equipment.
• Do not connect the instrument and the PC via a USB hub.
• Do not connect USB equipment other than ImageQuant LAS 4000 to the PC. Simi-
larly, do not use other USB equipment connected to the PC while ImageQuant LAS
4000 is in use. This may result in the loss of image data.
• The PC must be certified according to UL60950-1 (UL listed) and IEC60950-1.
USB cable
Connects ImageQuant LAS 4000
and the analysis PC. Read data will
be sent from ImageQuant LAS 4000
to the analysis PC through the USB
cable. USB 2.0 is supported.
Connect one end with the Image-
Quant LAS 4000 camera head USB
connector, and the other to a USB
port of the analysis PC.
ImageQuant LAS 4000
F0.85 43mm LAS high sensitivity lens
ImageQuant LAS 4000 User Manual 28-9607-42 AB
