5 Software reference guide
5.6 Start
During exposure (type Program)
No. Description
1 The range can be changed by dragging the
mouse.
2 Gradation can be changed by dragging the
mouse.
3 The gradation conversion curve can be
changed (linear or sigmoidal).
4 Return to initial setting.
5 The changed gradation is applied to all im-
ages.
TIP:
Note:
88
1 2 3 4
• Images for which exposure is completed are automatically saved in a file with name
format: <FileName>_<PhotographNo.>_<ExposureTime>
• An image, which is the accumulation of all exposed images is saved in a file with
name format: <FileName>_<Sum>_<TotalExposureTime>
Only the 16 latest exposed images can be saved for exposure type Program.
10
5 8 7
No. Description
6 Exposure is discontinued.
The current image is discarded.
7 Click this tab to enter index view.
8 Click this tab to magnify the latest image.
9 Preset conditions.
10 The area where an image will be displayed.
9
6
