Help Menu - GE ImageQuant LAS 4000 User Manual

Result: The following dialog is displayed.
1 Enter a Name for the method.
2 Select appropriate settings for Light, Filter and Iris.
3 Click OK.
Note:

5.13 Help menu

User Manual
Opens the ImageQuant LAS 4000 User Manual in the default pdf browser.
Getting Started
Opens the Getting Started with ImageQuant LAS 4000 manual in the default pdf browser.
End-User License Agreement
Opens the End-User License Agreement in the default pdf browser.
Sensitivity/Resolution
The figure showing the relation between sensitivity and resolution is displayed. Click to close the window.
ImageQuant LAS 4000 User Manual 28-9607-42 AB
Optical characteristics can be corrected using the Flat Frame Calibration function for the
added Method. See Section 5.12.2 Flat Frame Calibration, on page
5 Software reference guide
5.12 Option menu
5.12.3 Method Setting
105.
107
