VLT AQUA High Power Operation Instructions
Illustration 3.46: Inverter Cabinet, frame size F1 and F3
1)
External Temperature Monitoring
2)
AUX Relay
01
02
03
04
05
06
3)
NAMUR
4)
AUX Fan
100
101 102 103
L1
L2
L1
L2
5)
Brake
-R
+R
81
82
6)
Motor
U
96
T1
7)
NAMUR Fuse. See fuse tables for part numbers
8)
Fan Fuses. See fuse tables for part numbers
9)
SMPS Fuses. See fuse tables for part numbers
®
MG.20.P3.02 - VLT
is a registered Danfoss trademark
V
W
97
98
T2
T3
