Danfoss VLT AQUA High Power Operation Instructions Manual page 122

5 How to programme the frequency converter
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[130] Out frq 0-100 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
5
[133] Motor cur. 4-20mA
[134] Torq.0-lim 4-20 mA
[135] Torq.0-nom 4-20mA
[136] Power 4-20mA
[137] Speed 4-20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl t.o. 4-20mA
[143] Ext. CL 1 4-20mA
[144] Ext. CL 2 4-20mA
[145] Ext. CL 3 4-20mA
NB!
Values for setting the Minimum Reference is found in open loop par. 3-02
Feedb. - values for maximum reference for open loop is found in par. 3-03
Feedb.
.
6-51 Terminal 42 Output Min Scale
Range:
0.00 %* [0.00 - 200.00 %]
122
: 0 - Motor rated torque, (0-20 mA)
: 0 - Motor rated power, (0-20 mA)
: 0 - Speed High Limit (par. 4-13 and par. 4-14), (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100 Hz
: Minimum Reference - Maximum Reference
: -200% to +200% of par. 20-14
: 0 - Inverter Max. Current (par. 16-37
: 0 - Torque limit (par. 4-16)
: 0 - Motor rated torque
: 0 - Motor rated power
: 0 - Speed High Limit (par. 4-13 and par. 4-14)
: 0 - 100%, (0-20 mA)
: 0 - 100%
: 0 - 100%, (0-20 mA)
: 0 - 100%
: 0 - 100%
: 0 - 100%
: 0 - 100%
Minimum Reference
Maximum Reference
Function:
Scale for the minimum output (0 or 4 mA) of the analogue signal at terminal 42.
Set the value to be the percentage of the full range of the variable selected in par. 6-50
42 Output
.
®
MG.20.P3.02 - VLT is a registered Danfoss trademark
VLT AQUA High Power Operation Instructions
Inv. Max. Current
)
and for closed loop par. 20-13
and for closed loop par. 20-14
Minimum Reference/
Maximum Reference/
Terminal
