Frame size D1
A 277 (10.9)
B 227 (8.9)
C 173 (6.8)
D 179 (7.0)
E 370 (14.6)
F 300 (11.8)
G 222 (8.7)
H 139 (5.4)
I 55 (2.2)
J 354 (13.9)
K 284 (11.2)
L 334 (13.1)
M 250 (9.8)
N 167 (6.6)
O 261 (10.3)
P 170 (6.7)
Q 120 (4.7)
R 256 (10.1)
S 308 (12.1)
T 252 (9.9)
U 196 (7.7)
V 260 (10.2)
Table 3.1: Cable positions as shown in drawings above. Dimensions in mm (inch).
IP 21 (NEMA 1) / IP 54 (NEMA 12)
Frame size D2
379 (14.9)
326 (12.8)
273 (10.8)
279 (11.0)
370 (14.6)
300 (11.8)
226 (8.9)
142 (5.6)
59 (2.3)
361 (14.2)
277 (10.9)
334 (13.1)
250 (9.8)
167 (6.6)
260 (10.3)
169 (6.7)
120 (4.7)
350 (13.8)
332 (13.0)
262 (10.3)
192 (7.6)
273 (10.7)
®
MG.20.P3.02 - VLT is a registered Danfoss trademark
IP 00 / Chassis
Frame size D3 Frame size D4
119 (4.7) 122 (4.8)
68 (2.7) 68 (2.7)
15 (0.6) 16 (0.6)
20.7 (0.8) 22 (0.8)
363 (14.3) 363 (14.3)
293 (11.5) 293 (11.5)
215 (8.4) 218 (8.6)
131 (5.2) 135 (5.3)
48 (1.9) 51 (2.0)
347 (13.6) 354 (13.9)
277 (10.9) 270 (10.6)
326 (12.8) 326 (12.8)
243 (9.6) 243 (9.6)
159 (6.3) 159 (6.3)
261 (10.3) 261 (10.3)
170 (6.7) 170 (6.7)
120 (4.7) 120 (4.7)
98 (3.8) 93 (3.7)
301 (11.8) 324 (12.8)
245 (9.6) 255 (10.0)
189 (7.4) 185 (7.3)
260 (10.2) 273 (10.7)
