VLT AQUA High Power Operation Instructions
3.4.4 Input plate option
This section is for the field installation of input option kits available for frequency converters in all D and E frames.
Do not attempt to remove RFI filters from input plates. Damage may occur to RFI filters if they are removed from the input plate.
NB!
Where RFI filters are available, there are two different type of RFI filters depending on the input plate combination and the RFI filters
interchangeable. Field installable kits in certain cases are the same for all voltages.
380 - 480 V
380 - 500 V
D1 All D1 power sizes
D2 All D2 power sizes
E1 FC102/ 202: 315 kW
FC 302: 250 kW
FC102/ 202: 355 - 450 kW
FC 302: 315 - 400 kW
525 - 690 V
D1 FC102/ 202: 45-90 kW
FC302: 37-75 kW
FC102/202: 110-160 kW
FC302: 90-132 kW
D2 All D2 power sizes
E1 FC102/202: 450-500 kW
FC302: 355-400 kW
FC102/202: 560-630 kW
FC302: 500-560 kW
Kit contents
- Input plate assembled
- Instruction sheet 175R5795
- Modification Label
- Disconnect handle template (units w/ mains disconnect)
Cautions
- Frequency converter contains dangerous voltages when connected to line voltage. No disassembly should be attempted with
power applied
- Electrical parts of the frequency converter may contain dangerous voltages even after the mains have been disconnected.
Wait the minimum time listed on the drive label after disconnecting the mains before touching any internal components to
ensure that capacitors have fully discharged
- The input plates contain metal parts with sharp edges. Use hand protection when removing and reinstalling.
- E frames input plates are heavy (20-35 kg depending on configuration). It is recommended that the disconnect switch be
removed from input plate for easier installation and be reinstalled on the input plate after the input plate has been installed
on the drive
NB!
For further information, please see the Instruction Sheet,
Fuses Disconnect Fuses
176F8442 176F8450
176F8443 176F8441
176F0253 176F0255
176F0254 176F0256
Fuses Disconnect Fuses
175L8829 175L8828
175L8442 175L8445
175L8827 175L8826
176F0253 176F0255
176F0254 176F0258
175R5795
®
MG.20.P3.02 - VLT is a registered Danfoss trademark
RFI RFI Fuses
176F8444 176F8448
176F8445 176F8449
176F0257 176F0258
176F0257 176F0259
RFI RFI Fuses
175L8777 NA
175L8777 NA
175L8825 NA
NA NA
NA NA
3 How to Install
3
RFI Disconnect
Fuses
176F8446
176F8447
176F0260
176F0262
RFI Disconnect
Fuses
NA
NA
NA
NA
NA
