5 How to programme the frequency converter
5
5-13 Terminal 29 Digital Input
Option:
[0] * No Operation
5-14 Terminal 32 Digital Input
Option:
[0] * No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inv
[5] DC-brake inverse
[6] Stop inverse
[7] External interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[24] Set-up select bit 1
[34] Ramp bit 0
[36] Mains failure inverse
[37] Fire Mode
[52] Run permissive
114
controlled by the relay RELAY1. Variable speed pump (lead) cannot be interlocked in the basic Cas-
cade Controller.
See below table:
Setting in Par. 5-1* Setting in Par. 25-06
[0] No
[130] Pump1 Interlock Controlled by RELAY1
(only if not lead pump)
[131] Pump2 Interlock Controlled by RELAY2
[132] Pump3 Interlock Controlled by RELAY3
[133] Pump4 Interlock Controlled by RELAY4
[134] Pump5 Interlock Controlled by RELAY5
[135] Pump6 Interlock Controlled by RELAY6
[136] Pump7 Interlock Controlled by RELAY7
[137] Pump8 Interlock Controlled by RELAY8
[138] Pump9 Interlock Controlled by RELAY9
Function:
Same options and functions as par. 5-1*
Function:
Same options and functions as par. 5-1*, except for
®
MG.20.P3.02 - VLT is a registered Danfoss trademark
VLT AQUA High Power Operation Instructions
[1] Yes
Frequency Converter control-
led
(cannot be interlocked)
Controlled by RELAY1
Controlled by RELAY2
Controlled by RELAY3
Controlled by RELAY4
Controlled by RELAY5
Controlled by RELAY6
Controlled by RELAY7
Controlled by RELAY8
Digital Inputs
.
Pulse input
.
