Mechanical dimensions, frame size E and F
Frame Size E1
315 - 450 kW at
400 V
(380 - 480 V)
450 - 630 kW at
690 V
(525-690 V)
IP 21, 54
NEMA Type 1/ Type 12
Shipping di- Height
840 mm
mensions
Width 2197 mm
Depth 736 mm
Drive dimen-
Height 2000 mm
sions
Width 600 mm
Depth 494 mm
Max
313 kg
weight
Mechanical dimensions , Frame size D
D1
110 - 132 kW at 400 V 160 - 250 kW at 400 V
(380 - 480 V) (380 - 480 V)
45 - 160 kW at 690 V 200 - 400 kW at 690 V
(525-690 V) (525-690 V)
21 54 21
Type 1 Type 12 Type 1
650 mm 650 mm 650 mm
1730 mm 1730 mm 1730 mm
570 mm 570 mm 570 mm
1209 mm 1209 mm 1589 mm
420 mm 420 mm 420 mm
380 mm 380 mm 380 mm
104 kg 104 kg 151 kg
E2 F1
315 - 450 kW at 500 - 710 kW at
400 V 400 V
(380 - 480 V) (380 - 480 V)
450 - 630 kW at 710 - 900 kW at
690 V 690 V
(525-690 V) (525-690 V)
00 21, 54
Chassis Type 1/ Type 12
831 mm 2324 mm
1705 mm 1569 mm
736 mm 927 mm
1547 mm 2204
585 mm 1400
498 mm 606
277 kg 1004
®
MG.20.P3.02 - VLT is a registered Danfoss trademark
D2 D3
110 - 132 kW at 400 V
(380 - 480 V)
45 - 160 kW at 690 V
(525-690 V)
54 00
Type 12 Chassis
650 mm 650 mm
1730 mm 1220 mm
570 mm 570 mm
1589 mm 1046 mm
420 mm 408 mm
380 mm 375 mm
151 kg 91 kg
F2
800 - 1000 kW at 500 - 710 kW at
400 V 400 V
(380 - 480 V) (380 - 480 V)
1000 - 1200 kW 710 - 900 kW at
at 690 V 690 V
(525-690 V) (525-690 V)
21, 54 21, 54
Type 1/ Type 12 Type 1/ Type 12
2324 mm 2324 mm
1962 mm 2159 mm
927 mm 927 mm
2204 2204
1800 2000
606 606
1246 1299
3 How to Install
D4
160 - 250 kW at 400 V
(380 - 480 V)
200 - 400 kW at 690 V
(525-690 V)
00
Chassis
650 mm
1490 mm
570 mm
1327 mm
408 mm
375 mm
138 kg
F3 F4
800 - 1000 kW at
400 V
(380 - 480 V)
1000 - 1200 kW
at 690 V
(525-690 V)
21, 54
Type 1/ Type 12
2324 mm
2559 mm
927 mm
2204
2400
606
1541
