VLT AQUA High Power Operation Instructions
Illustration 3.36: Compact IP 21 (NEMA 1) and IP 54 (NEMA 12), frame size D1
Illustration 3.37: Compact IP 21 (NEMA 1) and IP 54 (NEMA 12) with disconnect, fuse and RFI filter, frame size D2
1) AUX Relay
01 02 03
04 05 06
2) Temp Switch
106 104 105
3) Line
R S T
91 92 93
L1 L2 L3
4) Load sharing
-DC +DC
88 89
5) Brake
-R
81
6) SMPS Fuse (see fuse tables for part number)
7) AUX Fan
100
L1
8) Fan Fuse (see fuse tables for part number)
9) Mains ground
10) Motor
U
96
T1
®
MG.20.P3.02 - VLT is a registered Danfoss trademark
+R
82
101 102 103
L2 L1 L2
V W
97 98
T2 T3
3 How to Install
3
