VLT AQUA High Power Operation Instructions
Illustration 3.14: IP21 (NEMA type 1) and IP54 (NEMA type 12) enclosure power connection position of disconnect switch
Frame size UNIT TYPE
IP54/IP21 UL AND NEMA1/NEMA12
250/315 kW (400V) AND 355/450-500/630 KW
E1
(690 V)
315/355-400/450 kW (400V)
DIMENSION FOR DISCONNECT TERMINAL
381 (15.0) 253 (9.9)
371 (14.6) 371 (14.6)
®
MG.20.P3.02 - VLT is a registered Danfoss trademark
253 (9.9) 431 (17.0) 562 (22.1)
341 (13.4) 431 (17.0) 431 (17.0)
3 How to Install
3
N/A
455 (17.9)
