3 How to Install
3.2.6 Rated Power
Frame size
3
Enclosure IP
protection NEMA
Normal overload
rated power - 110%
overload torque
Frame size
Enclosure IP
protection NEMA
Normal overload
rated power -
110% overload
torque
NB!
The F frames have four different sizes, F1, F2, F3 and F4 The F1 and F2 consist of an inverter cabinet on the right and rectifier cabinet
on the left. The F3 and F4 have an additional options cabinet left of the rectifier cabinet. The F3 is an F1 with an additional options
cabinet. The F4 is an F2 with an additional options cabinet.
24
D1
21/54
Type 1/ Type 12
110 - 132 kW at 400 V 150 - 250 kW at 400 V
(380 - 480 V)
45 - 160 kW at 690 V 200 - 400 kW at 690 V
(525-690 V)
E1
21/54
Type 1/ Type 12 Chassis
315 - 450 kW at 400 V 315 - 450 kW at 400 V
(380 - 480 V) (380 - 480 V)
450 - 630 kW at 690 V 450 - 630 kW at 690 V
(525-690 V) (525-690 V)
MG.20.P3.02 - VLT
VLT AQUA High Power Operation Instructions
D2
21/54
Type 1/ Type 12 Chassis
110 - 132 kW at 400 V
(380 - 480 V) (380 - 480 V)
45 - 160 kW at 690 V
(525-690 V) (525-690 V)
E2 F1/F3
00 21/54
Type 1/ Type 12
500 - 710 kW at 400 V
(380 - 480 V)
710 - 900 kW at 690 V
(525-690 V)
®
is a registered Danfoss trademark
D3 D4
00 00
Chassis
150 - 250 kW at 400 V
(380 - 480 V)
200 - 400 kW at 690 V
(525-690 V)
F2/F4
21/54
Type 1/ Type 12
800 - 1000 kW at 400 V
(380 - 480 V)
1000 - 1200 kW at 690 V
(525-690 V)
