5 How to programme the frequency converter
[55]
DigiPot increase
[56]
DigiPot decrease
[57]
DigiPot clear
[60]
Counter A (up)
[61]
Counter A (down)
[62]
Reset Counter A
[63]
Counter B (up)
[64]
Counter B (down)
[65]
Reset Counter B
[66]
Sleep Mode
[78]
Reset Maint. Word
[120]
Lead Pump Start
5
[121]
Lead Pump Alternation
[130]
Pump 1 Interlock
[131]
Pump 2 Interlock
[132]
Pump 3 Interlock
5-30 Terminal 27 Digital Output
Option:
[0] *
No operation
[1]
Control ready
[2]
Drive ready
[3]
Drive rdy/rem ctrl
[4]
Standby / no warning
[5]
Running
[6]
Running / no warning
[8]
Run on ref/no warn
[9]
Alarm
[10]
Alarm or warning
[11]
At torque limit
[12]
Out of current range
[13]
Below current, low
[14]
Above current, high
[15]
Out of speed range
[16]
Below speed, low
[17]
Above speed, high
[18]
Out of feedb. range
[19]
Below feedback, low
[20]
Above feedback, high
[21]
Thermal warning
[25]
Reverse
[26]
Bus OK
[27]
Torque limit & stop
[28]
Brake, no brake war
[29]
Brake ready, no fault
[30]
Brake fault (IGBT)
[35]
External Interlock
116
Function:
Same options and functions as par. 5-3*.
®
MG.20.P3.02 - VLT
is a registered Danfoss trademark
VLT AQUA High Power Operation Instructions
