VLT AQUA High Power Operation Instructions
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC Brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[36] Set digital out E low
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
NB!
For choices [32] - [43], see also par. group 5-3*,
23-02 OFF Time
Array [10]
Range:
0 N/A* [0 - 0 N/A]
Digital Outputs and 5-4*, Relays .
Function:
Sets the OFF time for the Timed Action.
NB!
The frequency converter has no back up of the clock function and the set date/
time will reset to default (2000-01-01 00:00) after a power down unless a Real
Time Clock module with back up is installed. In par. 0-79
to program for a Warning in case clock has not been set properly, e.g. after a
power down.
®
MG.20.P3.02 - VLT is a registered Danfoss trademark
5 How to programme the frequency converter
5
Clock Fault
it is possible
