6 General Specifications
Mains Supply 3 x 525- 690 VAC
Output current
6
Max. input current
178
P45K
Typical Shaft output at
37
550 V [kW]
Typical Shaft output at
50
575 V [HP]
Typical Shaft output at
45
690 V [kW]
Enclosure IP21 D1
Enclosure IP54 D1
Enclosure IP00 D2
Continuous
56
(at 550 V) [A]
Intermittent (60 sec
overload) 62
(at 550 V) [A]
Continuous
54
(at 575/ 690 V) [A]
Intermittent (60 sec
overload) 59
(at 575/ 690 V) [A]
Continuous KVA
53
(at 550 V) [KVA]
Continuous KVA
54
(at 575 V) [KVA]
Continuous KVA
65
(at 690 V) [KVA]
Continuous
60
(at 550 V ) [A]
Continuous
58
(at 575 V ) [A]
Continuous
58
(at 690 V ) [A]
Max. cable size, mains,
motor, load share and
brake [mm 2 (AWG)]
Max. external pre-fuses
125
[A] 1
Estimated power loss
at rated max. load [W]
1398
4) , 575 V
Estimated power loss
at rated max. load [W] 1458
4) , 690 V
Weight,
enclosure IP21, IP 54
[kg]
Weight,
enclosure IP00 [kg]
Efficiency 4) 0.97
Output frequency
Heatsink overtemp. trip
Power card ambient
trip
MG.20.P3.02 - VLT
VLT AQUA High Power Operation Instructions
P55K P75K
45 55
60 75
55 75
D1 D1
D1 D1
D2 D2
76 90
84 99
73 86
80 95
72 86
73 86
87 103
77 89
74 85
77 87
2x70 (2x2/0)
160 200
1645 1827
1717 1913
96
82
0.97 0.98
0 - 600 Hz
85 °C
60 °C
®
