The CS software provides the following data via OPC connections. All items listed below have read-only
access.
Item
Synchronization
.System is synchronized
Graphic
.Maximum temperatures
.Minimum temperatures
.Average temperatures
Live Ring Migration system
.Rings
.Ring 1.Time
.Ring 1.Offset
.Ring 1.State
Alarm zones
.Zone 1.Maximum temperature limit
.Zone 1.Hysteresis (low)
.Zone 1.Maximum temperature
.Zone 1.Alarm State
Devices
.Kiln.Rotation velocity
.Kiln.Lap time
.Kiln.Snapshot Counter
.Kiln.Points of reading
.Scanner 1.State
.Scanner 1.Internal temperature
.Pyrometer 1.State
.Pyrometer 1.Internal temperature
.Pyrometer 1.Maximum temperature
.Pyrometer 1.Dirty lens alarm limit
.Pyrometer 1.Dirty lens alarm state
.Pyrometer 1.Type
.Pyrometer 2.Burning zone
CS210
Type Description
Bool Flag for indicating that the system runs synchronized to the oven
Integer array Provides the Maximum Temperature Profile (temperature via pixel number)
Integer array Provides the Minimum Temperature Profile (temperature via pixel number)
Integer array Provides the Average Temperature Profile (temperature via pixel number)
Integer Number of rings currently used for Live Ring Migration
Integer Revolution time for ring 1
Integer Offset time for ring 1 compared to kiln revolution time
Bool Status for ring 1
Integer Upper alarm threshold for zone 1
Integer Hysteresis for zone 1 (reset threshold for an alarm)
Integer Maximum temperature for zone 1
Bool Alarm status for zone 1
Integer Rotation velocity for the kiln given in rpm
Integer Rotation time for the kiln
Integer Snapshot counter, will be increased by 1 with each new stored image into the database, can be
used as live counter
Integer array Provides the Length Profile of the kiln (location of each pixel)
Bool Status for scanner 1
Integer Internal temperature for scanner 1
Bool Status for pyrometer 1
Integer Internal temperature for pyrometer 1
Integer Maximum temperature for pyrometer 1
Integer Threshold for dirty lens alarm for pyrometer 1 (shadow pyrometer only)
Bool Dirty lens alarm status for pyrometer 1 (shadow pyrometer only)
String Pyrometer used for: <burningZone> or <shadowPyrometer>
Integer Temperature of the burning zone for pyrometer 2 (burning zone pyrometer only)
