RayTek CS210 Instruction Manual page 118

Drawings
W1 – Power Supply 24 V, 3-pin
Description
1 GND power ground
2
3 + 24 VDC input for + 24 VDC power supply voltage
shield
W2 – RS485 Interface, 7-pin
Description
1 GND Ground, (connected to power ground)
2 T+ RS485 transmit
3 T- RS485 transmit
4 R+ RS485 receive
5 R- RS485 receive
6 n.c.
7 + 12 VDC regulated voltage for the RS232/485 converter
shield
W3 – Alarm, Trigger, 6-pin
Description
1 Relay contact Potential free relay contact, capacity max. 30 V, 1 A.
2 Relay contact Potential free relay contact, capacity max. 30 V, 1 A
3 Trigger + Trigger input: + 5 to + 24 VDC
4 Trigger - Trigger input GND
5 Functional input Not used
6 Functional input Not used
shield
118
Rev. B4 Feb 2015
Color (6 wires)
brown
not connected
white
black
Color (6 wires)
gray
brown
white
green
yellow
pink
Color (6 wires)
brown
white
green
yellow
pink
gray
black
CS210
