6. Configuration

The following sections of this manual describe the operation of the CS software. Complete
configuration requires the following steps:
1. Install the software.
2. Configure the system.
a. Provide detail of certain general options.
b. Define detail of visual appearance options.
c. Define temperature reading instruments (scanners and pyrometers).
d. List alarm zones and refractory details.
e. Need for controlling of fans
f. Provide detail of the LRM system installation.
g. Define preferences for storing historical data.
Before proceeding with the following sections please ensure that the physical installation
(communication and power wiring, air, water if necessary, etc.) is completed and working
satisfactorily.

6.1 Software Installation

The software installation requires the user as local administrator with full permission
whereby the administrator requires a dedicated password (network and non-password
accounts do not work).
It is strongly recommended to update the Windows operating system before installing
the CS software!
Make sure that the default SQL port 1433 is not in use; otherwise you will be not able to
install the software.
Disable all energy saving functions of the operating system like automatic shutdown,
energy saving modes, and hard drive spin down!
Insert the software DVD in the DVD drive and double click on the <Setup.exe> file. The install setup
application will start, showing the following steps in a screen window.
When the install setup starts up, a welcome screen will show, letting you select the default
•
language for the application. Once you have selected the language, click on <Next> to
continue.
Next, select the path where you want to install the application and the folder where you want
•
the database to be installed. When finished, click on <Next>.
