W10 from the fan control output module to the system connection box. This four-wire-cable is
used for data communication and power supply to the output module.
W14 from the MI connection box to the system connection box and between MI connection boxes
–
when more than one shadow sensor is installed. This four-wire cable is used for data
communication and power supply to the pyrometer.
W15 from the MR connection box to the system connection box. This six-wire cable is used for
–
data communication and power supply to the pyrometer.
–
W16 MI sensing head cable.
W17 MR sensing head cable.
–
W18 Ethernet communication cable for scanner (preinstalled with system connection box)
–
W20 Fibre optic cable from system connection box to the control room and to the second scanner
–
(if used). Fibre optic cable to be provided by customer.
W22 Ethernet cable from fibre optic converter (control room) to the PC.
–
–
W23 from the position indicator head to the junction box.
W24 Power supply cable 100 to 240 VAC.
–
W25 Fibre optic cable from the first scanner to the second scanner (if used). Fibre optic cable to be
–
provided by customer.
All copper cables must be shielded! The wires from W9, W10, W14, and W15 must be a
twisted pair! Local building codes should be observed when selecting cables!
CS210
Rev. B4 Feb 2015
Pre-Installation
15
