RayTek CS210 Instruction Manual page 16

Kiln shell temperature monitoring system
Table of Contents

Advertisement

Pre-Installation
Cable
Distance
W1, W2,
7.5 m (25 ft.)
W3
W8
350 m (380 yd)
W9
350 m (380 yd)
W10
350 m
(380 yd)
W14
350 m (380 yd)
350 m (380 yd)
W15
350 m (380 yd)
W16
8 m (26 ft)
W17
15 m (49 ft.)
W18
7.5 m (25 ft.)
W20
< 2 km (1.2 mi)
W22
2 m (6.5 ft.)
W23
5 m (15 ft.)
W24
W25
< 2 km (1.2 mi)
The cable length causes a certain voltage drop on the power cable. In case of using
multiple sensors (MI shadow pyrometers via W14), longer cable lengths, or less gauges
it must always be ensured, that the sensor will be supplied with the minimal voltage
power!
Linescanner:
MR burning zone pyrometer:
MI shadow pyrometer:
16
Cable features
preinstalled
3 x 0.25 mm²,
24 AWG, 3 conductor, shielded
3 x 2 x 0.25 mm²,
24 AWG, 3x twisted pair, shielded
2 x 2 x 0.25 mm²,
24 AWG, 2 x twisted pair, shielded
2 x 2 x 0.5 mm²,
20 AWG, 2 x twisted pair, shielded
2 x 2 x 1.5 mm²,
16 AWG, 2 x twisted pair, shielded
3 x 2 x 1.5 mm²,
16 AWG, 3x twisted pair, shielded
preinstalled
preinstalled
Fibre optic cable (outdoor),
2 fibres, multi-mode, 62.5/125 µm or
50/125 µm, equipped with SC
connectors
Ethernet patch cable (CAT5, RJ-45)
Power supply cable 100 to 240 VAC,
50 / 60 Hz, min. 3 x 1.5 mm² (16 AWG)
Fibre optic cable (outdoor),
2 fibres, multi-mode, 62.5/125 µm or
50/125 µm, equipped with SC
connectors
min. 18 VDC
min. 20 VDC
min. 12 VDC
Rev. B4 Feb 2015
Supplied from ...
Example / Remarks
Raytek
Customer
(N)YLHCY-J 3 × 0.25 mm²
Manhattan/CDT, P/N M13233
Customer
LifYCY 3 × 2 × 0.25 mm²
Customer
Customer
max. 5 pyrometers
Customer
max. 14 pyrometers
Customer
Raytek
Raytek
Raytek
Customer
Standard cable designation:
A-DQ(ZN)B2Y...
Raytek
Raytek
Customer
NYY
Customer
Standard cable designation:
A-DQ(ZN)B2Y...
