Web Page Item
Keypad 8
Keypad 9
Keypad 0
Keypad *
Keypad #
Call Button
Button Tones
Play Button Tones
2.4.6.1 Dial Out Extension Strings and DTMF Tones (using rfc2833)
On the Button Configuration page, dial out extensions support the addition of comma delimited
pauses and sending additional DTMF tones (using rfc2833). The first comma will pause three
seconds after a call is first established with a remote device. Subsequent commas will pause for 2
seconds. A pause of one second will be sent after each numerical digit.
Extension String
302
302,2
302,25,,,4,,1
Note
Operations Guide
Table 2-9. Button Configuration Parameters (continued)
Description
Dial this extension when the 8 key is pressed.
Dial this extension when the 9 key is pressed.
Dial this extension when the 0 key is pressed.
Dial this extension when the * key is pressed.
Dial this extension when the # key is pressed.
Dial this extension when the call button is pressed.
Play a tone when the keypad buttons are pressed.
Click the Save button to save your configuration settings.
Click on the Reboot button to reboot the system.
Click on the Start button to start a button test.
Click on the Toggle Help button to see a short description of some of the web page
items. First click on the Toggle Help button, and you will see a question mark (
next to some of the web page items. Move the mouse pointer to hover over a question
mark to see a short description of a specific web page item.
Table 2-10. Examples of Dial-Out Extension Strings
Resulting Action
Dial out extension 302 and establish a call
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2'
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF
tone 4, wait 4 seconds, send out DTMF tone 1
The maximum number of total characters in the dial-out field is 25.
931562B
Installing the SIP Outdoor Intercom with Keypad
CyberData Corporation
39
Intercom Setup
) appear
