2. On the Button Configuration page, you may enter values for the parameters indicated in
Web Page Item
Dial Mode
Enable Telephone Operation
Enable Cellphone Operation
Enable Speed Dial Operation
Enable Security Operation
Security Mode Settings
Relay Activation Code
Relay Deactivation Code
Allow Telephone Dialout
Call Button
ID
Send Multicast Audio
Multicast Address
Multicast Port
Repeat Message
Speed Dial Settings
Speed Dial Timeout
Keypad 1
Keypad 2
Keypad 3
Keypad 4
Keypad 5
Keypad 6
Keypad 7
Operations Guide
Table 2-9.
Table 2-9. Button Configuration Parameters
Description
Dial extensions like a normal telephone. Pressing the call button will start a dial tone.
Pressing the call button in a call will cancel a call.
Enter your extension and press the call button to start the call. Press the call button again
to cancel the call.
In speed dial mode every button can be configured to call a different extension when
pressed.
Security mode allows the user to secure the local or remote relay by requiring a code (up
to 8 digits) to be entered into the device's keypad. The security codes may be entered
within a phone call to a preset extension or independently. Security codes start with the
pound key (#) and will be recognized when the user stops pressing buttons or hits the
pound key again.
Activation code used to activate the relay when entered on a phone during a SIP call with
the device. Relay will be active indefinitely, or until the DTMF Relay Deactivation code is
entered. Enter up to 25 digits (* and # are supported).
Code used to deactivate the relay when entered on a phone during a SIP call with the
device. Enter up to 25 digits (* and # are supported).
When enabled, the user will be able to use the keypad to dial while the device is in
Security mode.
Dial this extension when the call button is pressed. Up to 64 characters.
Type the desired Extension ID. Up to 64 characters.
When selected, the device will play an audio file to the specified multicast address and
port.
Note: The keypad must be in Security mode to send Multicast Audio.
The multicast address used for multicasting an audio file.
The multicast port used for multicasting an audio file.
The number of times to repeat the audio message to the remote endpoint. Enter a value
from 1-65536.
The amount of time you must hold the button before it calls the configured extension.
When this is set to 0 the phone will dial the configured extension as soon as the button is
released.
Dial this extension when the 1 key is pressed.
Dial this extension when the 2 key is pressed.
Dial this extension when the 3 key is pressed.
Dial this extension when the 4 key is pressed.
Dial this extension when the 5 key is pressed.
Dial this extension when the 6 key is pressed.
Dial this extension when the 7 key is pressed.
