2. On the Sensor page, enter values for the parameters indicated in
Note
Web Page Item
Door Sensor Settings
Door Sensor Normally Closed
Door Open Timeout (in seconds)
Flash Button LED
Activate Relay
Play Audio Locally
Make call to extension
Dial Out Extension
Dial Out ID
Play recorded audio
Repeat Sensor Message
Intrusion Sensor Settings
Flash Button LED
Activate Relay
Play Audio Locally
Make call to extension
Dial Out Extension
Dial Out ID
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-19. Sensor Configuration Parameters
931562B
Installing the SIP Outdoor Intercom with Keypad
) in the following table shows which web page items will be defined
.
Description
Select the inactive state of the door sensor. The door sensor is
also known as the Sense Input on the device's terminal block.
The time (in seconds) the device will wait before it performs an
action when the on-board door sensor is activated. The action(s)
performed are based on the configured Door Sensor Settings
below. Enter up to 5 digits.
When selected, the Call button LED will flash until the on-board
door sensor is deactivated (roughly 10 times/second).
When selected, the device's on-board relay will be activated until
the on-board door sensor is deactivated.
When selected, the device will loop an audio file out of the
speaker until the door sensor is deactivated.
When selected, the device will call an extension when the on-
board door sensor is activated. Use the Dial Out Extension field
below to specify the extension the device will call.
Specify the extension the device will call when the on-board door
sensor is activated. Enter up to 64 alphanumeric characters.
An additional Caller identification string added to outbound calls.
Enter up to 64 alphanumeric characters.
When selected, the device will call the Dial Out Extension and
play an audio file to the phone answering the SIP call
(corresponds to Door Ajar on the Audiofiles page).
The number of times to repeat the audio message through the
local speaker or to the remote endpoint. A value of 0 will repeat
forever. Enter a value from 0-65536.
When selected, the Call button LED will flash until the intrusion
sensor is deactivated (roughly 10 times/second).
When selected, the device's on-board relay will be activated until
the intrusion sensor is deactivated.
When selected, the device will loop an audio file out of the
speaker until the intrusion sensor is deactivated.
When selected, the device will call an extension when the
intrusion sensor is activated. Use the Dial Out Extension field
below to specify the extension the device will call.
Specify the extension the device will call when the intrusion
sensor is activated. Enter up to 64 alphanumeric characters.
An additional Caller identification string added to outbound calls.
Enter up to 64 alphanumeric characters.
Intercom Setup
Table 2-19.
