A.7.3 Goose Neck Mounting Option (Not Provided)
Figure A-11
Note: To mount the intercom, use methods
compliant with local electrical codes.
For Gooseneck Mounting
with Optional Shroud
Remove Hole Plug
for Shroud Installation
1/4" Washer (3x)
1/4" Nut (3x)
J1
(to Ground Lug)
Inside 3-Gang Box
Faceplate Mounting
Screw (6x) Faceplate &
PCB Assembly
Operations Guide
illustrates a gooseneck mounting option for the SIP Outdoor Intercom with Keypad.
Figure A-11. Optional Goose Neck Mounting
Assembly prior
Ground Cable
#8 Nut
Apply RTV Silicone Sealant
Around Hole
Shroud (Optional)
(Sold Separate)
Apply RTV * Gooseneck, Grounding Rod,
Clamp, Network Cable & Ground Cable,
Silicone Sealant
RTV Sealant are Not Provided
Around Mounting Holes
931562B
Additional Mounting Options
Gooseneck
1/4" Round Head
Carriage Bolt (3x)
CyberData Corporation
111
Gooseneck
[Cutaway View
to Show
Cable Routing]
Network
Cable in
