CyberData 011214 Operation Manual page 111

Sip outdoor intercom with keypad
Hide thumbs Also See for 011214:
Table of Contents

Advertisement

Figure A-3. Unit Dimensions—Faceplate and Board Assembled
ø0.156 [ø3.96] Through Hole
82 Degrees Countersunk (6 Places)
3.181 [80.80]
3.181 [80.80]
0.559 [14.21]
7.480 [190.00]
2.043 [51.89]
Dimensions are in Inches [Millimeter]
