CyberData 011214 Operation Manual page 42

Web Page Item
Relay Pulse Duration (in seconds)
Relay Activation Code
Relay Deactivation Code
Play tone during DTMF Activation
Activate Relay During Ring
Activate Relay During Night Ring
Activate Relay While Call Active
Activate Relay on Button Press
Relay on Button Press Duration
Misc Settings
Device Name
Auto-Answer Incoming Calls
Button Lit When Idle
Button Brightness (0-255)
Keypad Lit When Idle
Keypad Brightness (0-255)
Play Ringback Tone
Enable Push to Talk
Operations Guide
Table 2-8. Device Configuration Parameters (continued)
Description
The length of time (in seconds) during which the relay will be activated
when the DTMF Relay Activation Code is detected. Enter up to 5 digits.
Activation code used to activate the relay when entered on a phone during a
SIP call with the device. Relay will be active indefinitely, or until the DTMF
Relay Deactivation code is entered. Activate Relay with DTMF Code must
be enabled. Enter up to 25 digits (* and # are supported).
Code used to deactivate the relay when entered on a phone during a SIP
call with the device. Activate Relay with DTMF Code must be enabled. Enter
up to 25 digits (* and # are supported).
When selected, the device will play a tone out of the speaker upon DTMF
relay activation. The tone plays for the DTMF Activation Duration (in
seconds).
When selected, the relay will be activated for as long as the device is
ringing. When Auto-Answer Incoming Calls is enabled, the device will not
ring and this option does nothing.
When selected, the relay will be activated as long as the Nightringer
extension is ringing.
When selected, the relay will be activated as long as the SIP call is active.
When selected, the relay will be activated when the Call button is pressed.
The length of time (in seconds) during which the relay will be activated
when the Call button is pressed. Enter up to 5 digits. A Relay on Button
Press Duration value of 0 will pulse the relay once when the Call button is
pressed.
Type the device name. Enter up to 25 characters.
When selected, the device will automatically answer incoming calls. When
Auto-Answer Incoming Calls is disabled, the device will play a ring tone
(corresponds to Ring Tone on the Audiofiles page) out of the speaker until
someone presses the Call button to answer the call or the caller
disconnects before the call can be answered.
When selected, the Call button LED is illuminated while the device is idle (a
call is not in progress).
The desired Call button LED brightness level. Acceptable values are 0-255,
where 0 is the dimmest and 255 is the brightest. Enter up to three digits.
When selected, the keypad is illuminated while the device is idle (a call is
not in progress).
The desired keypad brightness level. Acceptable values are 0-255, where 0
is the dimmest and 255 is the brightest. Enter up to three digits.
When selected, the device will play a ringback tone (corresponds to
Ringback Tone on the Audiofiles page) out of the speaker while placing an
outbound call. The Ringback Tone will play until the call is answered.
This option is for noisy environments. When enabled, the microphone will
be muted normally. When the Call button is pressed and held, it will unmute
the microphone and allow the operator to send audio back. Using Push to
Talk prevents the operator from terminating a call by pressing the Call
button. The call must be terminated by the phone user.
931562B
Installing the SIP Outdoor Intercom with Keypad
CyberData Corporation
35
Intercom Setup
