10. Technical Data

10.1. Environmental
Ambient
Temperature
Altitude
Relative Humidity
10.2. Input/Output Power and Current Ratings
The following tables provide the output current rating information for the various Optidrive P2 models. Invertek Drives always
recommend that selection of the correct Optidrive is based upon the motor full load current at the incoming supply voltage.
10.2.1. 200 – 240 Volt (+/- 10%),1 Phase Input, 3 Phase Output
Frame Power
Size Rating
kW
2 0.75
2 1.5
2 2.2
NOTE
 Ratings shown above apply to 40°C Ambient temperature. For derating information, refer to section 10.4. 1 .
 T he maximum motor cable length stated applies to using a shielded motor cable. When using an unshielded cable, the maximum
cable length limit may be increased by 50%. When using the Invertek Drives recommended output choke, the maximum cable
length may be increased by 100%.
 T he PWM output switching from any inverter when used with a long motor cable length can cause an increase in the voltage at the
motor terminals, depending on the motor cable length and inductance. The rise time and peak voltage can affect the service life of
the motor. Invertek Drives recommend using an output choke for motor cable lengths of 50m or more to ensure good motor service
life.
 F or UL compliant installation, use Copper wire with a minimum insulation temperature rating of 70°C, UL Class CC or Class J
Fuses.
10
Storage and Transportation All Units
Operating IP20 Units -10 ... 50°C / 14 ... 122°F
IP55 Units - 10 ... 40°C / 14 ... 104°F
IP66 Units - 10 ... 40°C / 14 ... 104°F
Operating All Units
Operating All Units
Input Fuse or MCB
Current (Type B)
HP A Non UL
1 8.5 10
1.5 15.2 25
1.5 19.5 25
-40 ... 60°C / -40 ... 140°F
40 ... 50°C / 104 ... 122°F
40 ... 50°C / 104 ... 122°F
=<1000m
=<4000m
< 95%
Maximum Cable
Size
UL mm AWG/kcmil
15 8 8
20 8 8
25 8 8
UL Approved
With derating (refer to section 10.4. 1 . Derating for
Ambient Temperature on page 72)
UL Approved
With derating (refer to section 10.4. 1 . Derating for
Ambient Temperature on page 72)
With UL approval
With derating (refer to section 10.4.2. Derating for
Altitude on page 72)
Non-condensing, frost and moisture free
Rated Maximum Recommended
Output Motor Cable
Current Length
A m ft
4.3 100 330
7 100 330
10.5 100 330
Brake
Resistance
Ω
100
50
35
