Invertek Drives Optidrive ODP-2 User Manual page 58

8.4.4. Parameter Group 9 – User Inputs and Output Programming
Par. Function
P9-01
Enable Input Source
P9-02
Fast Stop Source
P9-03
Run Forward Source
P9-04
Run Reverse Source
P9-05
Latch Enable
P9-06
Reverse Input Source
P9-07
Reset Source
P9-08
External Trip Source
P9-09
Terminal Control Override Source
P9-10
Speed Setpoint 1
P9-11
Speed Setpoint 2
P9-12
Speed Setpoint 3
P9-13
Speed Setpoint 4
P9-14
Speed Setpoint 5
P9-15
Speed setpoint 6
P9-16
Speed Setpoint 7
P9-17
Speed Setpoint 8
P9-18
Reference Select Bit 0
P9-19
Reference Select Bit 1
P9-20
Reference Select Bit 2
P9-21
Preset Speed Select Bit 0
P9-22
Preset Speed Select Bit 1
P9-23
Preset Speed Select Bit 2
P9-24
Acceleration Ramp Select Bit 0
P9-25
Acceleration Ramp Select Bit 1
P9-26
Deceleration Ramp Bit 0
P9-27
Deceleration Ramp Bit 1
P9-28
MOP Up Source
P9-29
MOP Down Source
P9-30
Speed Limit Switch Forward
P9-31
Speed Limit Switch Reverse
P9-33
Analog Output 1 Control
P9-34
Analog Output 2 Control
P9-35
Relay 1 Control
P9-36
Relay 2 Control
P9-37
Display Scaling Control
P9-38
PID Setpoint Control
8
P9-39
PID Feedback Control
P9-40
Torque Reference Control
P9-41
Relay 3, 4 and 5 Control
58 | Optidrive P2 User Guide | Version 3.00
Setting Range Default
These parameters allow the user to directly select the source of the various command points.
Parameters are only adjustable if P1-13 = 0. This allows complete flexibility over the drive
control functions, and interaction with the internal Function Block programming environment.
0 Disabled
1 Enabled
See above
In combination with P9-18 – P9-20, allow selection of several speed reference sourcesfor
common applications.
See above
0 P2-1 1
1 Function Block Digital
2 Function Block Analog
0 P2-13
1 Function Block Digital
2 Function Block Analog
0 P2-15
1 Function Block Digital
0 P2-18
1 Function Block Digital
0 P2-21
1 Function Block Digital
0 P3-05
1 Function Block Digital
0 P3-10
1 Function Block Digital
0 P4-06
1 Function Block Digital
0 Default Settings
1 Function Block Digital
Notes
0
0 These parameters allow the user to overdide
the normal parameter control source for the
associated function, allowing interaction with the
internal Function Block programming environment.
0
0
0
0
0
0
0
0
