2. General Information and Ratings
This chapter contains information about the Optidrive E3 including how to identify the drive.
2.1. Identifying the Drive by Model Number
Each drive can be identified by its model number, as shown in the table below. The model number is on the shipping label and the
drive nameplate. The model number includes the drive and any options.
ODE -
Product Family
Generation
Frame Size
Input Voltage
1 = 1 10 – 1 15
2 = 200 – 240
4 = 380 – 480
2.2. Product Rating Label Location
All Optidrive E3 models carry a rating label, which can be located as follows:
2.3. Understanding the Rating Label
The product rating label provides the following information.
Key
1
Model Code
2
Enclosure Type and IP Rating
3
Firmware Version
4
Serial Number
5
Technical Data – Supply Voltage
Technical Data – Maximum continuous
6
output current
www.invertekdrives.com
3
-
1
2
0021 -
On right hand side when
viewed from the front.
1
4
2
3
1
F
1
A
Dynamic Brake
OPTIDRIVE E3
ODE-3-120023-1F1B
Serial No.:
11111111111
Input
Output
IP66 / NEMA 4X
V
200-240
0-250
S/Ware : v
3.06
Ø
1
3
F(Hz)
50/60
0-500
817020
I (A)
3.7
2.3
Made in the UK
kW
0.37
www.invertekdrives.com
HP
0.5
Risk of Electric Shock
Power down for
Read User Guide before
5min before
installation or servicing
removing
SCCR: For rating and
cover
protection refer to
CAUTION
User Guide
Version 1.00 | Optidrive ODE-3 IP66 Outdoor Rated User Guide | 5
IP Rating
A = IP66 Non Switched
B = IP66 Switched
1 = Not Fitted
Transistor
4 = Internal Transistor
Filter Type
0 = No Filter
F = Internal EMC Filter
No. Of Input Phases
Output Current x 10
5
6
2
