Introduction
CB-7000 is a family of network data acquisition and control modules. They provide A/D, D/A, DI/O,
Timing/Counting and other functions. These modules can be remote controlled by a set of commands.
The common features of the CB-7080 and CB-7080D include:
Two independent 32-bit counters, counter 0 and counter 1.
Input signals can be isolated or non-isolated.
Programmable digital filter for isolated and non-isolated input.
External gate control for isolated and non-isolated input.
Programmable threshold value for non-isolated input.
Programmable alarm output.
Input frequency measurement up to 100 kHz.
The CB-7080D module identical to the CB-7080 with a 5-digit LED display added. The LEDs can display the
counter value and input signal frequency without PC control.

Comparing the 7080 and 7080D

Table 1-1 summarizes the features of the CB7080 and CB7080D modules.
5-digit LED display
Response to LED command
Module name
Counter preset value
Alarm on counter 0 only
Alarm on counter 0 and 1
Channel 0 and channel 1 are both non-
isolated (input mode 0, $AAB0)
Channel 0 and channel 1 are both
isolated (input mode 1, $AAB1)
Channel 0 is non-isolated and channel
1 is isolated (input mode 2, $AAB2)
Channel 0 is isolated and channel 1 is
non-isolated(input mode 3, $AAB3)
Input frequency
Default setting
Table 1-1. Comparison between CB-7080 and CB-7080D
CB-7080
No
No
programmable
Yes (programmable)
Yes (programmable)
Yes (programmable)
Yes
Yes
Yes
Yes
100 kHz max.
4080 compatible
High alarm on counter 0
and 1
Counter preset value: 0
CB-7080D
Yes
Yes
programmable
Yes (programmable)
Yes (programmable)
Yes (programmable)
Yes
Yes
Yes
Yes
100 kHz max.
4080D compatible
High/High-High alarm on counter 0
Counter preset value: 0
