CB-7080 & CB-7080D Counter/Timer User's Guide

$AA6N

Description : Reset counter 0 or counter 1 to the preset value and clear the overflow flag. Refer to
value setting" for more information.
Syntax : $AA6N[chk](cr)
$
AA
N=0
N=1
[chk]
(cr)
:
Response
Valid response
Invalid response
no response
!
?
AA
[chk]
(cr)=0x0D
Examples :
Reads preset value of Counter 0.
command:
response:
Preset value=0xABCD:
command:
response:
Reset counter 1 to preset value 0xABCD:
command
response
command:
response:
A delimiter character
2-character HEX module address, from 00 to FF
Counter 0
Counter 1
2-character checksum. If checksum is disabled, no [chk]
0x0D
!AA[chk](cr)
?AA[chk](cr)
Syntax error, communication error or address error
A delimiter character indicating a valid response
A delimiter character indicating an invalid response
2-character HEX module address
2-character checksum. If checksum is disabled, no [chk]
@01G0(cr)
!0100000000(cr)
$0160(cr)
!01(cr)
@01G1(cr)
010000ABCD(cr)
$0161(cr)
!01(cr)
2-24
$AA6N
"Preset
