CB-7080 & CB-7080D Counter/Timer User's Guide

$AA2

Description: Read the configuration of module.
: $AA2[chk](cr)
Syntax
$
AA
[chk]
(cr)
Response :
Valid response:
Invalid response:
no response:
!
?
AA
TT
CC
FF
[chk]
(cr)
Examples :
Address=01, counter, 9600 BPS, checksum disabled:
command:
response:
Address=02, frequency, 19200 BPS, checksum disabled:
command:
response:
Note
If you use the %AANNTTCCFF command to change module configuration, the new configuration code is
stored into EEPROM immediately.
The configuration code includes the module address, module type, baud rate code, checksum enable/disable
code, calibration code, power-on value and safe value.
The EEPROM data of a CB-7080 can be read an infinite number of times, and can be written about 100,000
times maximum. Therefore, you should not frequently change the configuration code for testing.
The $AA2 command is used to read EEPROM data only. You can send this command to CB-7080 module
without limit.
A delimiter character
2-character HEX module address, from 00 to FF
2-character checksum. If checksum is disabled, no [chk].
0x0D
!AATTCCFF[chk](cr),
?AA[chk](cr)
Syntax error, communication error or address error
A delimiter character indicating a valid response
A delimiter character indicating an invalid response
2-character HEX module address
Refer to Table 1-10.
Refer to Table 1-8.
Refer to Table 1-9.
2-character checksum. If checksum is disabled, no [chk].
0x0D
$012(cr)
!01500600(cr)
$022(cr)
!02510700(cr)
2-17
$AA2
