CB-7080 & CB-7080D Counter/Timer User's Guide

@AADO0D

Description : Set digital output.
: @AADO0D[chk](cr)
Syntax
@
AA
DO0
D=0
D=1
D=2
D=3
[chk]
(cr)
:
Response
Valid response
Invalid response
alarm is enabled
no response
!
?
AA
[chk]
(cr)
Examples :
Turn all D/O OFF:
command:
response:
Turn D/O ON; Turn D/O 1 OFF:
command:
response:
Note:
If the alarm is enabled, D/O 0 and D/O 1 will always be controlled by the module. Therefore the following
D/O conditions will exist:
- Power-on value is changed to hi/lo condition immediately.
- The @AADO0D command is ignored.
A delimiter character
2-character HEX module address, from 00 to FF
D/O0=D/O1=OFF
D/O0=ON, D/O1=OFF
D/O0=OFF, D/O1=ON
D/O0=D/O1=ON
2-character checksum. If checksum is disabled, no [chk]
0x0D
!AA[chk](cr)
?AA[chk](cr)
?AA[chk](cr)
Syntax error, communication error or address error
A delimiter character indicating a valid response
A delimiter character indicating an invalid response
2-character HEX module address
2-character checksum. If checksum is disabled
0x0D
@01DO00(cr)
!01(cr)
@02DO01(cr)
!02(cr)
no [chk]
2-38
