CB-7080 & CB-7080D Counter/Timer User's Guide

$AA1H

Description : Reads the high trigger level of non-isolated input. Refer to
setting" on page 1-8 for more information.
Syntax : $AA1H[chk](cr)
$
AA
[chk
(cr)
:
Response
Valid response
Invalid response
no response
!
?
AA
(data)
[chk]
(cr)
Examples :
High trigger level=2.4 volts:
command:$011H(cr)
response:
High trigger level=3.0 volts:
command:
response:!0230(cr)
A delimiter character
2-character HEX module address, from 00 to FF
2-character checksum. If checksum is disabled, no [chk].
0x0D
!AA(data)[chk](cr)
?AA[chk](cr)
Syntax error, communication error or address error
A delimiter character indicating a valid response
A delimiter character indicating an invalid response
2-character HEX module address
2-character decimal value for high trigger level. The unit is 0.1 volt and the range
can be from 0.0 to 5.0 volts.
2-character checksum. If checksum is disabled, no [chk].
0x0D
!0124(cr)
$021H(cr)
"Programmable threshold voltage
2-13
$AA1H
