CB-7080 & CB-7080D Counter/Timer User's Guide

$AA8V

Description : Select LED Configuration.
: AA8V[chk](cr)
Syntax
$
AA
V=0
V=1
V=2
[chk]
(cr)
Response :
Valid response
Invalid response
no response
!
?
AA
[chk]
(cr)
Examples :
LED shows channel 1:
command:
response:
HOST will control LED:
command:
response:
command:
response:
A delimiter character
2-character HEX module address, from 00 to FF
LED shows counter/frequency channel 0
LED shows counter/frequency channel 1
HOST control LED
2-character checksum. If checksum is disabled, no [chk]
0x0D
!AA[chk](cr)
?AA[chk](cr)
Syntax error, communication error or address error
A delimiter character indicating a valid response
A delimiter character indicating an invalid response
2-character HEX module address
2-character checksum. If checksum is disabled, no [chk]
0x0D
$0181(cr)
!01(cr)
$0282(cr)
!02(cr)
$029040.00(cr)
!02(cr)
2-27
