CB-7080 & CB-7080D Counter/Timer User's Guide
Command
$AA1L
$AA1L(data)
$AA3N
$AA3N(data)
$AA4
$AA4S
$AA5N
$AA5NS
$AA6N
$AA7N
$AAA
$AAAG
$AAB
$AABS
@AADI
@AADO0D
@AAGN
@AAPN(data)

Alarm mode 0 commands

Command
@AAEAN
@AADAN
@AAPA(data)
@AASA(data)
@AARP
@AARA

Alarm mode 1 commands

Command
@AAEAT
@AACA
@AADA
@AAPA(data)
@AASA(data)
@AARP
@AARA

LED commands

Command
$AA8
$AA8V
$AA9(data)
Response Description
!AA(data) Read the low trigger level
!AA Set the low trigger level
!AA(data) Read the max. counter value
!AA Set the max. counter value
!AAS Read the filter status
!AA Set the filter status
!AAS Read the counter status
!AA Set the counter status
!AA Reset the counter
!AAS Read the overflow status
!AAG Read the gate control mode
!AA Set the gate control mode
!AAS Read the input mode
!AA Set the input mode
!AAS0D00 Read the D/O and alarm state
!AA Set the D/O value
!AA(data) Read the preset value
!AA Set the preset value
Table 2-4. Alarm-mode 0 Command Set
Response Description
!AA Enable the alarm
!AA Disable the alarm
!AA Set the counter 0 alarm value
!AA Set the counter 1 alarm value
!AA Read the counter 0 alarm value
!AA Read the counter 0 alarm value
Table 2-5. Alarm-mode 1 Command Set
Response Description
!AA Enable the alarm
!AA Clear the latch alarm
!AA Disable the alarm
!AA Set the Hi-alarm value
!AA Set the Hi-Hi-alarm value
!AA Read the Hi-alarm value
!AA Read the Hi-Hi-alarm value
Table 2-6. LED Command Set
Response Description
!AAS Read LED configuration
!AA Set LED configuration
!AA Send data to LED
2-3
General syntax format
Reference
Page 2-15
Page 2-16
Page 2-18
Page 2-19
Page 2-20
Page 2-21
Page 2-22
Page 2-23
Page 2-24
Page 2-25
Page 2-29
Page 2-30
Page 2-31
Page 2-32
Page 2-36
Page 2-38
Page 2-44
Page 2-45
Reference
Page 2-39
Page 2-43
Page 2-46
Page 2-48
Page 2-50
Page 2-52
Reference
Page 2-40
Page 2-41
Page 2-42
Page 2-46
Page 2-48
Page 2-51
Page 2-53
Reference
Page 2-26
Page 2-27
Page 2-28
