CB-7080 & CB-7080D Counter/Timer User's Guide
Delimiter characters
The characters %, #, ~, %, $, @ are used as the leading character in a command. These characters indicate the
type of command to execute.
Delimiter Character
%
#
~
$
[ ]
(cr)
!

General Commands

Command
%AANNTTCCFF
#AAN
~**
~AA0
~AA1
~AA2
~AA3ETT
~AAO(name)
$AA2
$AAF
$AAI
$AAM

Frequency commands

Command
$AAB
$AABS
$AA1H
$AA1H(data)
$AA1L
$AA1L(data)

General counter commands

Command
~AAAS
$AA0H
$AA0H(data)
$AA0L
$AA0L(data)
$AA1H
$AA1H(data)
Usage
Set the configuration of a module.
Reset the data.
Get/set (read/write) module information.
Characters inside [ ] indicate optional code characters, such as [chk]
Indicates the end of the command.
Always the leading character in the response to a command.
Table 2-1. General Command Set
Response Description
!AA Set the module configuration
>(data) Read the counter or frequency
No Response Host OK
!AASS Read the module status
!AA Reset the module status
!AATT Read the Host Watchdog Timer
!AA Enable the Host Watchdog Timer
!AA Set the module name
!AATTCCFF Read the module configuration
!AA(data) Read the firmware number
!AAS Read the value of INIT* pin
!AA(data) Read the module name
Table 2-2. Frequency Command Set
Response Description
!AAS Read the input mode
!AA Set the input mode
!AA(data) Read the high trigger level
!AA Set the high trigger level
!AA(data) Read the low trigger level
!AA Set the low trigger level
Table 2-3. General Counter Command Set
Response Description
!AA Set the counter alarm mode
!AA(data) Read the minimum width of High
!AA Set the minimum width of High
!AA(data) Read the minimum width of Low
!AA Set the minimum width of Low
!AA(data) Read the high trigger level
!AA Set the high trigger level
2-2
General syntax format
Reference
Page 2-4
Page 2-1
Page 2-2
Page 2-3
Page 2-4
Page 2-5
Page 2-6
Page 2-8
Page 2-17
Page 2-33
Page 2-34
Page 2-35
Reference
Page 2-31
Page 2-32
Page 2-13
Page 2-14
Page 2-15
Page 2-16
Reference
Page 2-7
Page 2-9
Page 2-10
Page 2-11
Page 2-16
Page 2-13
Page 2-14
