CB-7080 & CB-7080D Counter/Timer User's Guide

$AAAG

Description : Set gate control mode. Refer to
: $AAAG[chk](cr)
Syntax
$
AA
G=0
G=1
G=2
[chk]
(cr)
Response :
Valid response
Invalid response
no response
!
?
AA
G=0
G=1
G=2
[chk]
(cr)
Examples :
Module 1 gate is active low:
command:
response:
Module 2 gate is active high:
command:
response:
Module 3 gate is disabled (always active):
command:
response:
"Gate control
A delimiter character
2-character HEX module address, from 00 to FF
Gate is low active
Gate is high active
Gate is disabled
2-character checksum. If checksum is disabled, no [chk]
0x0D
!AA[chk](cr)
?AA[chk](cr)
Syntax error, communication error or address error
A delimiter character indicating a valid response
A delimiter character indicating an invalid response
2-character HEX module address
Gate is low active
Gate is high active
Gate is disabled
2-character checksum. If checksum is disabled, no [chk]
0x0D
$01A0(cr)
!01(cr)
$02A1(cr)
!02(cr)
$03A2(cr)
!03(cr)
setting" for more information.
2-30
