CB-7080 & CB-7080D Counter/Timer User's Guide

@AADI

Description : Read the status of the D/O and the alarm. Refer to
output application notes", and
Syntax : @AADI[chk](cr)
@
AA
D=0
D=1
D=2
D=3
I
[chk]
(cr)
Response :
Valid response
Invalid response
no response
!
?
AA
D=0
D=1
D=2
D=3
Alarm mode 0:
S=0
S=1
S=2
S=3
Alarm mode 1:
S=0
S=1
S=2
[chk]
(cr)
"D/O operation principles" for more information.
A delimiter character
2-character HEX module address, from 00 to FF
D/O0=D/O1=OFF
D/O0=ON, D/O1=OFF
D/O0=OFF, D/O1=ON
D/O0=D/O1=ON
2-character checksum. If checksum is disabled, no [chk]
0x0D
!AAS0D00[chk](cr)
?AA[chk](cr)
Syntax error, communication error or address error
A delimiter character indicating a valid response
A delimiter character indicating an invalid response
2-character HEX module address
D/O0=D/O1=OFF
D/O0=ON, D/O1=OFF
D/O0=OFF, D/O1=ON
D/O0=D/O1=ON
counter 0 alarm=disabled, counter 1 alarm=disabled
counter 0 alarm=enabled, counter 1 alarm=disabled
counter 0 alarm=disabled, counter 1 alarm=enabled
counter 0 alarm=enabled, counter 1 alarm=enabled
counter 0 alarm=disabled
counter 0 alarm=enabled and MOMENTARY mode
counter 0 alarm=enabled and LATCH mode
2-character checksum. If checksum is disabled, no [chk]
0x0D
"Counter alarm mode
2-36
@AADI
selection", "Digital
